Ultraminiature Angular Position Sensor Based on the Beta-Voltaic Principle
Journal article   Peer reviewed

Ultraminiature Angular Position Sensor Based on the Beta-Voltaic Principle

Ezzat G. Bakhoum and Marvin H. M. Cheng
IEEE transactions on instrumentation and measurement, Vol.64(2), pp.533-540
02/01/2015
DOI: https://doi.org/10.1109/TIM.2014.2345932
Web of Science ID: WOS:000347518800025

Metrics

55 Record Views
5 Times Cited - Web of Science

Abstract

This paper introduces a new type of angular position sensor that features very high sensitivity and ultraminiature size, by comparison with other angular position sensors of the same dimensions. The sensor is based on the beta-voltaic principle. It consists of a radioactive β-particle source and a silicon p-n junction (acting as a detector). Both the source and the detector are semicircular in shape. If the source is positioned fully above the p-n junction, maximum dc voltage is obtained from the junction. As the angular position of the source is varied, the junction's output voltage drops in magnitude. The sensor measures 8 mm (diameter) × 0.7 mm (thickness). It can measure angular position as well as angular velocity. This new sensor will be ideal in applications such as digital cameras, smart tablets and cell phones, microrobotics, and so forth.
