Simulation and determination of grounding grid parameters in non-symmetrical shapes
Conference proceeding   Peer reviewed

Simulation and determination of grounding grid parameters in non-symmetrical shapes

Thyago G. Pires, Carlos L. B. da Silva, Wesley P. Calixto, Diogo N. Oliveira, Aylton J. Alves, Elder G. Domingues, Jose L. Domingos and Geovanne P. Furriel
2015 IEEE 13th Brazilian Power Electronics Conference and 1st Southern Power Electronics Conference (COBEP/SPEC), pp.1-5
Brazilian Power Electronics Conference and 1st Southern Power Electronics Conference (COBEP/SPEC), 13th (Fortaleza, Brazil, 11/29/2015–12/02/2015)
02/2016
DOI: https://doi.org/10.1109/COBEP.2015.7420186

Metrics

1 Record Views

Abstract

ground grid ground resistance leakage current mesh voltage Soil step voltage touch voltage Electrical Engineering or Electronics
This paper deals with the calculation of ground resistance, surface voltage, touch voltage and step voltage, to mesh with horizontal wires arranged in different angles. The mathematical modeling is based on the method proposed by Heppe, which allows obtaining the grounding parameters for soil stratified in two layers. Moreover, the results obtained by the Variable Currents Method (VCM) have been compared to traditional methods and the simplified method of ANSI-IEEE Std. 80/2013. They also present the results using a grounding grid non-symmetrical with conductors on various angles.
