Conference proceeding
Computation of grounding grids parameter on unconventional geometry
2015 CHILEAN Conference on Electrical, Electronics Engineering, Information and Communication Technologies (CHILECON), pp.523-527
CHILEAN Conference on Electrical, Electronics Engineering, Information and Communication Technologies (CHILECON) (Santiago, Chile, 10/28/2015–10/30/2015)
02/2016
Abstract
This paper deals with the computation of ground resistance, surface voltage, touch voltage and step voltage, to mesh with horizontal wires arranged in different angles. The computer program implemented used in the mathematical modeling is based on the method proposed by Heppe, which allows obtaining the grounding parameters for homogeneous soil and soil stratified in two layers. Furthermore, the results obtained by the Variable Currents Method (VCM) have been compared to traditional methods and the simplified method of ANSI-IEEE Std. 80/2013. They also present the results using a grounding grid with wires on various angles.
Related links
Details
- Title
- Computation of grounding grids parameter on unconventional geometry
- Publication Details
- 2015 CHILEAN Conference on Electrical, Electronics Engineering, Information and Communication Technologies (CHILECON), pp.523-527
- Resource Type
- Conference proceeding
- Conference
- CHILEAN Conference on Electrical, Electronics Engineering, Information and Communication Technologies (CHILECON) (Santiago, Chile, 10/28/2015–10/30/2015)
- Publisher
- IEEE
- Number of pages
- 5
- Copyright
- © 2015, IEEE
- Identifiers
- 99381851992306600
- Academic Unit
- Cybersecurity and Information Technology; Hal Marcus College of Science and Engineering
- Language
- English
