A Novel Discrete Variable Stiffness Gripper Based on the Fin Ray Effect
Conference proceeding   Peer reviewed

A Novel Discrete Variable Stiffness Gripper Based on the Fin Ray Effect

Jiaming Fu, Han Lin, I. V. S. Prathyush, Xiaotong Huang, Lianxi Zheng and Dongming Gan
Intelligent Robotics and Applications: 15th International Conference, ICIRA 2022, Harbin, China, August 1–3, 2022, Proceedings, Part III, pp.791-802
Lecture Notes in Artificial Intelligence
International Conference on Intelligent Robotics and Applications (ICIRA), 15th (Harbin, China, 08/01/2022–08/03/2022)
01/01/2022
DOI: https://doi.org/10.1007/978-3-031-13835-5_71
Web of Science ID: WOS:000870682100071

Metrics

Abstract

Variable stiffness grippers can adapt to objects with different shapes and gripping forces. This paper presents a novel variable stiffness gripper (VSG) based on the Fin Ray effect that can adjust stiffness discretely. The main structure of the gripper includes the compliant frame, rotatable ribs, and the position limit components attached to the compliant frame. The stiffness of the gripper can be adjusted by rotating the specific ribs in the frame. There are four configurations for the gripper that were developed in this research: a) all ribs OFF (Flex) mode; b) upper ribs ON and lower ribs OFF (Hold) mode; c) upper ribs OFF and lower ribs ON (Pinch) mode; d) all ribs ON (Clamp) mode. Different configurations can provide various stiffness for the gripper's finger to adapt the objects with different shapes and weights. To optimize the design, the stiffness analysis under various configurations and force conditions was implemented by finite element analysis (FEA). The 3-D printed prototypes were constructed to verify the feature and performance of the design concept of the VSG compared with the FEA results. The design of the VSG provides a novel idea for industrial robots and collaborative robots on adaptive grasping.
